Sun Yeh Compact Actuators T Series provide with torque of 6 Nm and 15 Nm. This compact actuator designs for a small space and applies to small valve and damper applications.

Features

- Compact size can install in small space.

- Comply to: NEMA 4X dry-powder coated aluminum alloy cover (Optional).

- Manual operation can be applied in case of electric failure.

- Built-in thermal protection prevents motor burning out.

- Simple design, easy operation.

PRODUCTION STANDARDS

1. DESIGN:                  TS EN 1171
2. END CONNECTION:  FLANGED TS EN 1092-2 / ISO 7005-2
3. FACETOFACE:         TS EN558Seri14/DIN3202F4TEST           TS EN12266-1

1. MARKING:               TSEN19

PRODUCTION STANDARDS

OM series electric actuators offer a range of 35 Nm~4500 Nm torque. The actuator comes standard with NEMA 4X (IP67) environmental rating. All models are ISO 5211 compliant and have a visual position indicator. The manual override can be operated without clutch and brake under our research and development.

Enclosure

● IP67, NEMA 4X : Water-proof and dust-proof enclosure.
● Material : Dry powder coating aluminum alloy.

Motor

● F (Standard) or H (Optional) insulation class for all models.
● Built-in thermal protection prevents motor burning out.
   AC motor : 125±5/257±9^oF  DC motor : 90±5/ 194±9 ^oF

Duty Cycle

● All models : 30% duty cycle (Standard)
● Extended duty cycle : (Optional)
  OM-A, OM-A-M, OM-1~OM-8 : 75% duty cycle
  OM-9~OM-13 : 50% duty cycle uty cycle

Position Indicator

All models have continuous mechanism position indicator on the top of actuator cover.

PRODUCTION STANDARDS

DESIGN:                      TS EN 1171
END CONNECTION:      FLANGED TS EN 1092-2 / ISO 7005-2
FACE TO FACE:           TS EN 558 Seri 15 / DIN 3202 F5
TEST:                          TS EN 12266-1
MARKING:                   TS EN 19
