Applications:
For handling pure, raw and waste water as well as seawater in:
■ Water works
■ Irrigation and drainage pumping stations
■ Power stations
■ Industrial water supply
■ Fire fighting systems
■ Marine and offshore engineering
■ General applications in the petrochemical industry
■ Seawater desalination
Material*
|
Volute casing |
Grey cast iron/nodular cast iron/duplex cast steel |
|
Impeller |
Bronze/duplex cast steel |
|
Shaft |
Cr steel/duplex steel |
|
Shaft protecting sleeves |
Cr steel |
|
Casing wear rings |
Bronze/Cr steel |
|
Impeller wear rings (optional) |
Bronze/duplex steel |
|
*) Other materials on request |
Technical data
|
Pump sizes |
DN 80 - 350 |
3 to 14 in |
|
Impeller |
Up to 2,880 m3/h |
Up to 12,680 m3/h |
|
Shaft |
Up to 210 m |
Up to 689 ft |
|
Shaft protecting sleeves |
Up to 25 bar |
Up to 363 psi |
|
Casing wear rings |
Up to 80oC |
Up to 176oC |
Main applications
▪ Irrigation and drainage pumping stations
▪ Stormwater pumping stations
▪ Raw and clean water pumps in waterworks and waste water treatment plants
▪ Cooling water pumps in power stations and in industry
▪ Industrial water supply
▪ Water pollution and flood control
▪ Aquaculture
Applications:
For handling pure, raw and waste water as well as seawater in:
■ Water works
■ Irrigation and drainage pumping stations
■ Power stations
■ Industrial water supply
■ Fire fighting systems
■ Marine and offshore engineering
■ General applications in the petrochemical industry
■ Seawater desalination
Application
Main applications
▪ Irrigation and drainage pumping stations
▪ Stormwater pumping stations
▪ Raw and clean water pumps in waterworks and waste water treatment plants
▪ Cooling water pumps in power stations and in industry
▪ Industrial water supply
▪ Water pollution and flood control
▪ Aquaculture
|
