PRODUCTION STANDARDS

DESIGN:                      TS EN 1171
END CONNECTION:      FLANGED TS EN 1092-2 / ISO 7005-2
FACE TO FACE:           TS EN 558 Seri 15 / DIN 3202 F5
TEST:                          TS EN 12266-1
MARKING:                   TS EN 19


.

PRODUCTION STANDARDS

DESIGN:                 TS EN 593
END CONNECTION:  WAFER TYPE TS EN 1092-1 / ISO 7005-1
FACE TO FACE:        TS EN 558 Seri 20

                              ISO 5752 Seri 20

TEST:                      TS EN 12266-1
MARKING:               TS EN 19

Sun Yeh Compact Actuators T Series provide with torque of 6 Nm and 15 Nm. This compact actuator designs for a small space and applies to small valve and damper applications.

Features

- Compact size can install in small space.

- Comply to: NEMA 4X dry-powder coated aluminum alloy cover (Optional).

- Manual operation can be applied in case of electric failure.

- Built-in thermal protection prevents motor burning out.

- Simple design, easy operation.

PRODUCTION STANDARDS

1. DESIGN:                  TS EN 1171
2. END CONNECTION:  FLANGED TS EN 1092-2 / ISO 7005-2
3. FACETOFACE:         TS EN558Seri14/DIN3202F4TEST           TS EN12266-1

1. MARKING:               TSEN19
